This is a completely revised book in line with ';Outcome Based Education (OBE)' that is currently being followed by most universities. Also, the engineering drawings in the book have been prepared using the latest version of AutoCAD.
The book has all the assessment tools like assessment exercise, short questions with answers, fill in the blanks and multiple choice questions (MCQ).
Engineering Graphics Concepts and Conventions • Scales • Plane Curves in Engineering Practices • Visualization Concepts and Freehand Sketching • Orthographic Projections • Projections of Points • Projections of Straight Lines • Projections of Planes • Auxiliary Projections • Projections of Solids • Projections of Sectioned Solids • Development of Surfaces • Isometric Projection • Perspective Projection • Computer Aided Drafting
• Additional learning materials
• PowerPoint presentations
• Video lectures are available on the author's website www.EGlive.in.
