Engineering Graphics and Design: With Demonstrations of AutoCAD, CATIA & ANSYS

Engineering Graphics and Design: With Demonstrations of AutoCAD, CATIA & ANSYS

(0 Reviews)
  • ISBN : 9789352718726
  • Pages : 440
  • Binding : Paperback
  • Language : English
  • Imprint : Vikas Publishing
  • © year : 2018
  • Size : 6.75 X 9.5

Price : 299.00 239.20

This book is developed from the ground up to cover the syllabus announced by the AICTE in its latest model curriculum. It provides insights into traditional engineering graphics as well as treats of the subject using software AutoCAD, CATIA and ANSYS, through simple and well-explained examples along with an ample number of unsolved problems and MCQs. Screenshots have been provided after every step, making it simple to learn how to use the software for a specific solution. It targets all academics—students, and researchers as well as industry practitioners and engineers, involved in engineering drafting.
The book begins by introducing the role and application of engineering drawing and describing such basics as the types of drawing sheets, lines, planes, quadrants and angles of projection, and national and international drawing standards which it calls the basic grammar for engineering graphics as a language.
The book introduces the software—AutoCAD, CATIA and ANSYS emphasizing on their specific features. Equipping the reader with this ground knowledge it comes to the nitty-gritty of drawing various curves, projection of points in separate quadrants, projection of straight lines in various positions, various projections of plane surfaces, and solids like prism, pyramid, cylinder and cone. It then goes further to sections of solids wherein the placements of the cutting planes have been explained in various positions like perpendicular, parallel, and inclined to HP and VP. Having thus trained the drafter in handling the drafting tools the book graduates to more complicated material like fusion of one solid shape into another. It explores various types of them so that development of lateral surfaces of solids can be made and depicted isometrically and projected orthographically. Lastly, the book describes 3D modelling using CATIA, where solid models are drawn, and how 2D analysis is done using ANSYS.

• Keeping in view the traditional engineering drawing principles, the book extensively deals with computer-based engineering graphics
• Introduces all the relevant drawing standards, both Indian and International
• Extensively covers points, lines, planes, solid surfaces and all the salient projections
• Plenty of usage/demos of AutoCAD and Catia for solid or 3D modelling, and Ansys for 2D analysis
• Holds the hands of the students to introduce the above-said software with all their functionalities before moving on to applications
• Step-by-step treatment of all software methods using series of well-labelled screenshots
• A companion video of various exercises that provides a visual display of the problems being solved, and shows how to utilize various tools and utilities of the software used

1. Introduction to Engineering Drawing
2. Introduction to CAD Software
3. Engineering Curves
4. Projections of Point
5. Projection of Lines
6. Projection of Plane Surfaces
7. Projection of Solids
8. Sections of Solids
9. Intersection of solids
10. Development of Surfaces of Solids
11. Isometric Projection
12. Orthographic Projection
13. 3D Modeling
14. 2D Analysis
